Wind Turbine Bornay Bee 800 W 48V 5 blades with Bee 800/48 controller

Bee 800 swt is designed to work in parallel with solar systems. The combination of a wind turbine with a solar photovoltaic system guarantees a stable energy production in almost all weather conditions.

Technical specifications
Number of blades    5
Diameter    1,75 mts
Material    Injected nylon
Direction of rotation    Clockwise
Control System
1. Electronic regulator

Electrical specifications
Alternator    Three phases permanent magnet alternator
Magnets    Neodymium
Nominal power 800 W
Voltage    12, 24, 48 v
RPM @ 500
Regulator (off-grid)
12v 70Amp.
24v 35 Amp.
48v 18 Amp.
Inverter (grid connection)    Windvert 1200

Performance, windspeed
For turn on 3,5 m/s
For nominal power    12 m/s
Survival    60 m/s

Physical specifications
Windturbine weight    29 kg
Regulator weight    8 kg
Packaging
Dimmensions - weight 50 x 76 x 46 cm ; 0,17 m3 – 40,5 Kg
Warranty     2 years
