Orion-Tr Smart 12/24-15A (360W) Non-isolated DC-DC charger

Product Code: ORI122436140
266,73 EUR
VAT included
Stock limit
- +
icon Add to cart
The product is in stock

Delivery date: 10 days

Do you need help? +4 03744 99990

Product Details

GENERAL

Length: 186mm
Width: 80mm
Height: 130mm
Input Voltage: 10 – 17V
Output Voltage: 20 – 30V
Continuous Output Current: 15A
Max Output Current: 25A
Continuous Output Power: 430W at 25°C
Operating Temperature Range: -20 to +55°C
Warranty: 5 Years
 Data sheet - click here


  • Brand: Victron Energy
  • Weight: 1.92 kg
  • Description
  • Reviews (0)

Bluetooth Smart enabled

Any Bluetooth enabled smart phone, tablet or other device can be used to monitor, to change settings and to update the charger when new software features become available.

Fully programmable

  • Battery charge algorithm (configurable) or fixed output.
  • Smart alternator compatibility: engine running detection mechanism.

Adaptive 3-stage charge algorithm: bulk – absorption – float

  • For lead acid batteries it is important that during shallow discharges the absorption time is kept short in order to prevent overcharging of the battery. After a deep discharge the absorption time is automatically increased to make sure that the battery is completely recharged.
  • For lithium batteries absorption time is fixed, default 2 hours.
  • Alternatively, a fixed output voltage can be chosen.

Remote on-off

A remote on/off switch or relay contact can be connected to a two-pole connector.
Alternatively, the H terminal (right) of the two-pole connector can be switched to battery plus, or the L terminal (left) of the two pole connector can be switched to battery minus (or the chassis of a vehicle, for example).

All models are short circuit proof and can be paralleled to increase output current

An unlimited number of units can be connected in parallel.

High temperature protected

The output current will reduce at high ambient temperature.

IP43 protection

When installed with the screw terminals oriented downwards.

Screw terminals

No special tools needed for installation.

Input fuse (not replaceable)
